Suitable for the extrusion of PVC,PE, and other plastic material,mainly applied in the insulation or sheath extrusion of car cable,net wire,power cable,data wire,high frequency wire,building wire,electric wire.etc.The changed screw is suitable for extrusion of low smoke halogen free,nylon and other plastic material.
| Machine type | GF-50+35 |
| Pay off type | motorized/double-shaft |
| Screw diameter | Φ35 and Φ50 |
| Screw L/D | 35mm:16:1,50mm:26:1 |
| Max.extrusion output | 35mm:30kg/h,50mm:90kg/h |
| Motor power | 50mm:11KW ,35mm:2.2KW |
| Wire diameter | Φ0.6~Φ4.0mm |
| Cooling device | Folding type W/U type |
| Haul-off power | 2.2KW |
| Wire-storage length | 180-250m |
| Max. Line speed | 450m/min |
| Take-up type | Double shaft bundle packaging/shaft packaging |
| Item | qty. |
| single head Active pay-off | 1set |
| Vertical tension dancer | 1set |
| 50mm Main extruder | 1set |
| 35mm extruder for stripe extrusion | 1set |
| 1.5m pre-water cooling trough | 1set |
| Diameter gauge | 1set |
| Single layer main cooling trough | 1set |
| Dual wheel capstan | 1set |
| 9m horizontal type cable accumulator | 1set |
| 15KV high frequency spark tester | 1set |
| Meter counter | 1set |
| 400-630mm dual reel take up | 1set |
| Electrical control system (PLC control optional) | 1set |
| Powder device(optional) | 1set |
| Printer(optional) | 1set |
| Copper preheater | 1set |
Can be optional for PLC control,infuse color machine (for the production of double-color wire), etc. the concrete configuration can be adjustable according to client's requirement.
