Fiber Optic Cable Machine For Dry Loose Tube Production Line
i-suntop fiber optic cable machine 20220228.pdf
Mainly Application for 2-12 cores fiber optic loose tube without jelly.
| Model type | Φ50 |
| Applicable material | Modified PP&PBT |
| Pay-off bobbin size | Φ236*160*108*25.4mm/φ265*160*225*25.4mm |
| Cores | 1-12 |
| Pay-off tension | 0.4N-1.5N±0.05N |
| Loose tube OD | Φ1.6-3.0mm |
| Designed speed | Max.800m/min |
| Processing line speed | Max.500m/min |
| Take-up bobbin | PN630-800mm |
| Collateral loss | ≤0.02dB/km |
| Line length | ≤36m*4.5m*3.5m |
| Power | 70KW, AC380V ±10% 50HZ three-phase five-wire |
| Items | Qty. |
| 12heads fiber pay off | 1set |
| Electrostatic device removed | 1set |
| Jelly filling device | 1set |
| 50 extruder | 1set |
| Dryer +hopper 50kg | 1set |
| IPC+PLC program control systerm | 1set |
| 4 m mobile hot water tank + hot water tank | 2sets |
| Ф630mm single wheel capstan+Warm water spraying device | 1set |
| Ф630mm single wheel capstan+cold water spraying device | 1set |
| laser diameter gauge | 1set |
| Take up Tension dancer | 1set |
| dual-shaft take-up 630-800mm | 1set |
